Specials

Includes:

• 4th Axis Prep
• 8 spare M Code Functions
• Coolant Through Spindle Prep

Standard Accessories:

• Heat exchanger on electrical cabinet
• Closed loop spindle chiller
• Arm Type tool changer
• 8.4 LCD monitor
• Auger Type Conveyor with bucket
• Leveling feet and pads
• Side Flushing Facility – Water gun, Coolant Flushing gun
• 3-axis pretensioned ballscrews
• Fanuc OiMF Control
• Ethernet, USB, RS232, PCMCIA card slot
• Absolute Position Encoders
• Fanuc Control, Drives & Motors
• Automatic lubrication system
• Fully enclosed splash guard
• Dust-proof electrical cabinet
• Spindle air sealing
• 3-color signal light
• Rigid Tapping
• Spindle coolant nozzle
• Documentation Package
• Manual Pulse Generator
• Automatic Power Off
• Spindle Auto Flush/ Air Blast Device

Standard Accessories:

• 8″ Diameter with thru hole power chuck
• Spindle Bore: 65mm (2.6″). Draw Tube Bore: 52mm (2″)
• Hard jaw (8″): 1 set / Soft jaws (8″): 3 sets
• 10 station turret
• OD tool holder 2 (set)
• ID tool holder 3 (set)
• U-drill tool holder 2 (set)
• Standard morse taper socket: MT3 x 1 pc
• ID sleeve ¼”, 5/16”, 3/8”, ½”, 5/8”, 13/16”, 1”
• U sleeve 5/8”, 13/16”, 1”, 1-1/4”
• Box Way Construction
• Rapid feedrate for X & Z axes: 20 & 24 m/min ( 787 & 944 in/min )
• Servo Turret
• Automatic lubrication system
• AC spindle motor for headstock: 0i-TF ß8i spindle motor 11kw cont. / 15kw 30 min. 15 / 20 HP
• AC servo motor: 0i-TF C8iB for X axis: 1.2kw: C8i for Z axis: 1.2kw (1.6HP)
• Hydraulic system
• Work light
• Coolant tank system
• Chip conveyor (with chip bucket)
• Door interlock
• Quill movement adjustable by limit switch
• Heat exchanger
• Programmable tailstock
• Full enclosed splash guard
• One set of instruction manual
• Tool box with tool kits
• Automatic Power off
• Ball screw pretention
• Pallet size (L x W x H) 258*229*223mm

Standard Accessories:

• Heat Exchanger on Electrical Cabinet
• Closed Loop Spindle Chiller
• 8.4″ LCD Monitor
• Chip Conveyor with Bucket
• 4th Axis Prep
• 8 Spare M Code Functions
• Leveling Feet and Pads
• 3-Axis Pretensioned Ballscrews
• Automatic Lubrication System
• Fully Enclosed Splash Guard
• Dust Proof Electrical Cabinet
• Spindle Air Sealing
• 3-Color Signal Light
• Rigid Tapping
• Spindle Coolant Nozzle
• Operation and Maintenance Manual

Standard Accessories:

• Heat Exchanger on Electrical Cabinet
• Closed Loop Spindle Chiller
• 8.4″ LCD Monitor
• Chip Conveyor with Bucket
• 4th Axis Prep
• 8 Spare M Code Functions
• Leveling Feet and Pads
• 3-Axis Pretensioned Ballscrews
• Automatic Lubrication System
• Fully Enclosed Splash Guard
• Dust Proof Electrical Cabinet
• Spindle Air Sealing
• 3-Color Signal Light
• Rigid Tapping
• Spindle Coolant Nozzle
• Operation and Maintenance Manual

Standard Accessories:

• 6″ Diameter with thru hole power chuck
• Spindle Bore: 53mm (2″). Draw Tube Bore: 42mm (1.7″)
• Hard jaw (6″): 1 set / Soft jaws (6″): 3 sets
• 8 station turret
  • OD tool holder 2 (set)
  • ID tool holder 3 (set)
  • U-drill tool holder 2 (set)
  • Standard morse taper socket: MT3 x 1pc
  • ID sleeve ¼”, 5/16”, 3/8”, ½”, 5/8”, 13/16”
  • U sleeve 1/2”, 5/8”, 13/16”
• Rapid feedrate for X & Z axes: 24 m/min
• Servo Turret
• Automatic lubrication system
• AC spindle motor for headstock: 0i-TF ß8i spindle motor 11kw cont. / 15kw 30 min.
• AC servo motor: 0i-TF C8iB for X axis: 1.2kw: C8i for Z axis: 1.2kw (1.6HP)
• Hydraulic system
• Work light
• Coolant tank system
• Chip conveyor (with chip bucket)
• Door interlock
• Heat exchanger
• Manual tailstock
• 3-color signal light
• Automatic power off
• Safety door
• Full enclosed splash guard
• One set of instruction manual
• Tool box with tool kits
• Ball screw pretention

Standard Accessories:

• Fanuc 0i-TF control
• 10″ Diameter with thru hole power chuck
• Hard jaw (10″): 1 set / Soft jaws (10″): 3 sets
• 10 station turret
  • OD tool holder 2 (set)
  • ID tool holder 3 (set)
  • U-drill tool holder 2 (set)
  • Standard morse taper socket: MT3 x 1 pc
  • ID sleeve 5/16”,3/8”,1/2”,5/8”,13/16”,1”,1-1/4”
  • U sleeve 13/16”,1”,1-1/4”
• Hydraulic system
• Automatic lubrication system
• Work light
• Coolant tank system
• Chip conveyor (with tank)
• Door interlock
• Heat exchanger
• Programmable tailstock
• Full enclosed splash guard
• One set of instruction manual
• Tool box with tool kits
• Ball screw pretention
